Dsl Shrouded Bus Bar System

Product Description

Dsl Shrouded Bus Bar System

We are one of the leading manufacturer of Crane Bus bar systems Crane Bus bar system are used for the electrification of mobile equipment We have a comprehensive range of Bright light lite sparkle which is load monitoring system The bus bar system is manufactured under the strict supervision by highly experience and technically knowledgeable persons and is thoroughly checked before it is dispatched from the factory Separate conductors shall be provided for each phase

We are a key manufacturer of Heavy Conductor Bus Bar System which is used for the energizing of mobile equipment A safe low maintenance and economical way the Shrouded Bus Bar solves your mobile electrification requirements These systems can be designed to suit 60 to 1200 amperes Also there are various options accessories that can be customized for your conductor bar system or applications System components can be preassembled at the plant to help ease of installation Conductor bar is applicable in overhead crane runways trolleys hoists conveyors people movers and port cranes

Features Benefits

Cover with ultraviolet additive for outdoor locations

All conductors with high temperature cover 280F

Stainless steel conductors for corrosive conditions

Stainless steel epoxy coated and insulated hangers for wet corrosive environments

Factorybuilt expansion sections and anchors for control of expansion

Factorybent curved conductor section systems

Various covers for matching competitive systems

Specific long wear collector brushes for the systems

Bare conductors accessible for intense heat applications

All enclosed covers with flap for airborn contamination indoor outdoor versions

Heated conductor systems effective for ice prevention on outdoor system or freezer storage etc

Specifications

Amperage 60Amp1200Amp

GI 60 A to 125A

Aluminium125A to 500A

Copper jointless25A to 200A

Copper160A to 1200A

Length 45 m

Ampere Capacity 60A 100A 125A 160A 250A 400A 200A 315A

Impedance mill ohmM 345 276 182 032 028 020 030 028

DC Resistance Mill ohmsM 342 274 180 031 027 019 026 022

Standard Conductor Length 45 Meters 45 Meters 45 Meters
