Anti Collision Device
The Anti-collision system is a safety device to avoid to collision of two electric overhead travelling cranes working on the same rails. For one pair of cranes two set of anti-collision systems are required. Each set consists of an Emitter/ sensor module and a Reflector.
Specification:
Model No |
ACC 03 |
ACC 10 |
ACC 15 |
ACC 102 |
Supply voltage |
230V AC/110V AC ( User selectable) |
230V AC/110V AC ( User selectable) |
230V AC/110V AC ( User selectable) |
230V AC/110V AC ( User selectable) |
No of set points |
Single |
Single |
Single |
Single |
No of output/ relay |
Single relay/ single output |
Single relay/ single output |
Single relay/ single output |
Two relay/ two output |
Contacts rating |
3 Amps (max.) at 220V AC |
3 Amps (max.) at 220V AC |
3 Amps (max.) at 220V AC |
3 Amps (max.) at 220V AC |
Dimension |
180 mm x 145 mm x 55 mm |
180 mm x 145 mm x 55 mm |
180 mm x 145 mm x 55 mm |
180 mm x 145 mm x 55 mm |
Reflector size |
130 x 75 mm |
130 x 75 mm |
130 x 75 mm |
130 x 75 mm |
Housing |
Metal housing |
Metal housing |
Metal housing |
Metal housing |
Price:
![]() |
