Pin Joint Shrouded Bus Bar
420.0 INR/Meter
Product Details:
- Input Current Up to 125A/Phase (Model Dependent)
- Mounting Type Suspended/Ceiling Mounted
- Humidity Up to 95% RH, Non-Condensing
- Efficiency High (Losses < 1% at Rated Load)
- Phase 3 Phase
- Protection Level IP 23 up to IP 54 (Variant Dependent)
- Function Power Transmission and Distribution
- Click to View more
X
Pin Joint Shrouded Bus Bar Price And Quantity
- 100 Meter
- 420.0 INR/Meter
Pin Joint Shrouded Bus Bar Product Specifications
- IP 23 up to IP 54 (Variant Dependent)
- Power Transmission and Distribution
- Up to 95% RH, Non-Condensing
- Overhead Cranes, Monorails, Material Handling Systems
- Electric
- Up to 125A/Phase (Model Dependent)
- High (Losses < 1% at Rated Load)
- Suspended/Ceiling Mounted
- 3 Phase
- Joint Covers, End Caps, Hangers
Pin Joint Shrouded Bus Bar Trade Information
- GODAWN
- Yes
- Sample costs shipping and taxes has to be paid by the buyer
- AS PER REQUIREMENT
- All India
Product Description
Pin Joint Shrouded Bus Bar
Our organization is one of the eminent manufacturers suppliers traders and exporters of Pin Joint Shrouded Bus Bar This rigidly built bar has an optimal quality and excellent performance Our product is extremely strong and durable The unique design of this product ensures high resistivity against corrosion This precision engineered bar is utilized in several heavy Medium industrial in mobile electrification application Pin Joint Shrouded Bus Bar is economical safe maintenance free and is helpful in removing wiring errors
Features
- Excellent Lubricity and Electrical Conductivity
- Easy and Safe to Connect
- Top Quality and Economical prices
Superior Electrical Performance
Our Pin Joint Shrouded Bus Bar systems deliver excellent electrical efficiency with losses of less than 1% at rated load, supporting input currents up to 125A per phase. The electrolytic copper or aluminum conductors ensure optimal conductivity, while the rigid PVC shroud offers robust insulation and outstanding dielectric strength. Customers benefit from consistent voltage supply up to 660V and reliable operation across various industrial applications.
Advanced Insulation and Safety
The busbars feature a rigid, self-extinguishing PVC shroud that meets the highest fire resistance standards. With a dielectric strength exceeding 20kV/mm and offered in safety-enhancing colors like orange, black, and yellow, these systems are engineered for maximum protection. Optional IP23 to IP54 variants enable use in humid and harsh environments, while accessories like joint covers and end caps further enhance safety.
Flexible Installation and Longevity
Available in 3 or 4 conductor systems and typical four-meter sections, the pin joint design allows easy modular assembly with built-in expansion capabilities. Installation can be suspended or ceiling-mounted to suit diverse site layouts, and robust materials guarantee a service life of up to 15 years. This flexibility makes the system ideal for new installations or replacements, ensuring long-term value and reliability.
FAQs of Pin Joint Shrouded Bus Bar:
Q: How do I select the appropriate Pin Joint Shrouded Bus Bar model for my application?
A: Selection depends on your required rated current (60A, 100A, or 125A), number of conductors (3 or 4), and environmental conditions. Consider factors such as input current, voltage (up to 660V), and installation setting (indoor or outdoor) to choose the right model.Q: What are the main benefits of using a shrouded bus bar system over conventional open-type busbars?
A: Shrouded bus bars offer enhanced safety with rigid PVC insulation, reducing the risk of accidental contact. They provide higher fire resistance, better protection against environmental factors (up to IP54), and simplified, modular installation with expansion capability.Q: When should accessories like joint covers, end caps, and hangers be used?
A: Accessories are recommended during initial installation or any maintenance operation to safeguard joints, terminate bus bar ends securely, and provide structural support. They help maintain system integrity and extend service life.Q: Where can the Pin Joint Shrouded Bus Bar system be installed?
A: These systems are suitable for a wide range of industrial settings, including overhead cranes, monorails, material handling systems, and environments requiring high electrical safety. They support both indoor and outdoor use due to robust, weather-resistant construction.Q: What is the process for installing a pin joint shrouded bus bar?
A: Installation involves suspending or ceiling-mounting the bus bar sections, joining them with pin joints for secure electrical continuity and expansion, and finally fitting accessories such as joint covers and end caps for added safety. It is advisable to follow manufacturer instructions and use appropriate tools.Q: How long can I expect the bus bar system to last under typical conditions?
A: Our pin joint shrouded bus bars are engineered for long-term reliability, providing a service life of up to 15 years when installed and maintained correctly, even in demanding environments with up to 95% relative humidity.Q: What makes the shroud material particularly effective for insulation and safety?
A: The rigid PVC shroud is self-extinguishing and offers excellent dielectric strength above 20kV/mm. Its color-coded options and robust structure enhance both visibility for maintenance and safety for operational personnel.Tell us about your requirement
