Home » Products » Busbar System » Jointless Bus bar

Jointless Bus bar

Jointless Bus bar
Jointless Bus bar
Product Code : 11
Brand Name : CMK
Product Specifications
  • Condition
  • New
  • Usage
  • EOT CRANE
  • Power Source
  • Electric
Trade Information
  • Minimum Order Quantity
  • 20
  • Unit of Measure
  • Meter/Meters
  • Price
  • 1400 INR
  • FOB Port
  • GODAWN
  • Payment Terms
  • Cheque
  • Sample Available
  • Yes
  • Sample Policy
  • Free samples are available
  • Main Export Market(s)
  • Asia
  • Main Domestic Market
  • All India
Product Description
We have carved a niche in this domain as a leading manufacturer, exporter and supplier of an excellent quality Jointless Bus bar. This busbar is manufactured using top grade raw materials and pioneering techniques with the aid of latest machinery as per set standards under the strict guidance of experts. Finding its application in transport system, offered busbar is used to avoid joints to ensure proper flow of current. Moreover, we offer this Jointless Bus bar at reasonable rates to our esteemed patrons.

Features:
  • Easy to install
  • Supreme finish
  • Accurate dimension
  • Shock proof


  • Rail Length [mm]: 4.000

  • Outside-Dimensions of bar profile: 2.20" x 3.54" (56.0 mm x 90,0 mm)

  • Support Spacing: 6.56 ft (2 meters)

  • Operating Conditions: For indoor and outdoor applications

  • Track Configuration: Straight course; curve segments available by request

  • Current Range : 40 Amps, 60 Amps, 80 Amps, 100 Amps, 120 Amps, 140 amps, 160 Amps, 180 Amps, 200 Amps

  • Maximum Running Speed: 278.9 feet/minute (85 meters/minute)

Electrical properties:

  • Max. Voltage(V): 600

  • Rail Length [mm]: 4.000

  • Conductor cross section(mm2): 10 - 16 - 25 - 35 - 50

  • Resistance(ÃŽ© /km): 1.656 - 1.137- 0.713 - 0.522 - 0.337

  • Leakage resistance: CTI600-2, 7

  • Dielectric strength: 30-40KV/mm

  • Track Configuration: Straight course / Curve segments on request ( R≥ 1.2m )
